PCB Tools
pcbtools.es

Load a ZIP or RAR containing your Gerber files (exported from KiCad, Altium, EasyEDA…) to access the tools:

πŸ‘ Viewer
Visualise all layers stacked together
✏ Editor
Edit primitives and export modified ZIP
⬑ Gerber to 3D
Export 3D model (OBJ, STL, 3MF, PLY)
πŸ“„ Gerber to PDF
Generate vector PDF at true scale
'
